MWPY Permanent Magnetic Yoke

Name: MWPY Permanent Magnetic Yoke
Brand: Mag World NDT Systems
Price: 20000 INR
Availability: InStock

Price 20000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

MWPY Permanent Magnetic Yoke Specification

Test Range
Up to 30 mm material thickness

Max Height
Yoke leg opening up to 200 mm

Mounting Type
Handheld

Power Supply
Self-energized (No external power required)

Humidity
0 - 95% RH (non-condensing)

Features
Water-resistant, robust design, portable

Interface Type
Handheld

Equipment Type
Permanent Magnetic Yoke

Resolution
Fine (as per ASTM standards)

Hardness
Yoke body: >50 HRC

Application
Magnetic Particle Inspection

Number of Specimens
Single at a time

Automation Grade
Manual

Usage
Industrial flaw detection

Test Speed
Manual operation

Test Stroke
As per yoke leg length

Control Mode
Manual

Lifting Power
Minimum 18 kg on standard block

Accessories Supplied
Carrying Case and Instruction Manual

Magnetic Pole Distance
Adjustable 0 - 200 mm

Corrosion Resistance
Yes

Color
Black & Metallic

Finish
Powder Coated

Operating Position
Any orientation

Polarity
AC/DC optional (per model)

Body Material
Alloy Steel

Field Strength
>25 mT at contact face

MWPY Permanent Magnetic Yoke Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About MWPY Permanent Magnetic Yoke

Discover the noble MWPY Permanent Magnetic Yoke - a splendiferous advancement for industrial magnetic particle inspection. Its gilt-edged design is engineered with a robust, powder-coated alloy steel body and self-energized control, requiring no external power supply. This new release guarantees superior field strength (>25 mT) and corrosion resistance while efficiently detecting fine cracks and subsurface defects. With adjustable magnetic pole distance (0-200 mm), versatile AC/DC polarity, and effortless portability, it's ideal for manual flaw detection. Add to Cart now for advance purchase and elevate your inspection precision.

Comprehensive Directions and Versatile Applications

The MWPY Permanent Magnetic Yoke is tailored for both surface and sub-surface flaw detection. Use the device by placing it directly onto the test material, adjusting the yoke legs between 100 mm and 200 mm as required. Its robust build and precise operation make it suitable for a variety of industries, including automotive, railways, and steel fabrication. Its ability to operate in any orientation allows for efficient defect detection on diverse materials and specimen sizes.

Sample Availability and Export Packaging

MWPY Permanent Magnetic Yoke samples are available upon request, supporting buyers in evaluating this splendiferous tool before larger commitments. We offer secure, export-standard packaging-each yoke arrives in a dedicated carrying case with an instruction manual. With a focus on the global export market, the FOB port in India ensures timely arrival and smooth handling. Take advantage of this gilt-edged offer for qualitative industrial inspection equipment tailored to precise international needs.

FAQ's of MWPY Permanent Magnetic Yoke:

Q: How does the MWPY Permanent Magnetic Yoke enhance defect detection?

A: The yoke delivers instantaneous field strength exceeding 25 mT at the contact face, enabling accurate detection of fine cracks and defects both on the surface and sub-surface of a variety of metals.

Q: What surfaces and materials are suitable for applying the yoke?

A: It is ideal for ferromagnetic materials with thickness up to 30 mm and can be used on components of variable sizes due to adjustable pole distance and flexible yoke placement.

Q: When should I use AC or DC polarity models?

A: AC polarity is optimal for detecting surface cracks, while DC polarity excels in identifying sub-surface flaws. Choose the model best suited to your inspection requirements.

Q: Where can the MWPY Permanent Magnetic Yoke be used?

A: The yoke is designed for a variety of industrial environments such as workshops, manufacturing plants, and inspection stations, thanks to its water-resistant, corrosion-resistant, and portable structure.

Q: What is the process for conducting an inspection with this yoke?

A: Place the yoke on the test specimen, manually adjust the legs for optimal width, and proceed with magnetic particle inspection following the included instruction manual for reliable results.

Q: What are the benefits of advance purchase and how is the product secured for delivery?

A: Advance purchase ensures priority handling and quicker shipment. Each product is supplied with a secure carrying case and arrives via our export-marketed, FOB India port setup for safety and efficiency.
